Fuel Polishing
Phillips Fuel System's fuel oil purify systems are self-contained, pre-packaged and pre-wired units specifically designed to purify and filter stored diesel fuel. Preserving the integrity of the diesel fuel helps ensure trouble-free generator starts and reduces annual maintenance, contaminated fuel disposal and annual reservoir cleaning costs.
Maintaining clean and dry diesel fuel also discourages the growth of algae and bacteria while helping to reduce the need for expensive chemicals and biocide additives.
Phillips Fuel Systems's oil purify systems are fully automated with optional tank monitoring capabilities and are capable of servicing multiple tanks. At the heart of each system is a diesel fuel purifier that is a simple one step unit. It removes 100% of the free water and up to 98% of dust, dirt, and other normal and natural contaminants found in all diesel fuel. Even today's "clean" diesel fuel becomes contaminated all too easily during transportation and storage.
Unlike all other products on the market, the Phillips Fuel System's diesel fuel purifier performs this function without the use of a replaceable, changeable, or cleanable filter element, cartridge, or bowl. By removing contamination immediately before the fuel enters the engine's filter system, the purifier delivers cleaner fuel, (virtually eliminating filter clogging) and therefore greatly extends maintenance intervals.
Each System Includes:
- Weather proof NEMA 3R rated enclosure, with lockable door, rupture containment basin with leak detection sensor and 1/2" NPT plug drain port. Enclosure can be ordered for either wall mounting or with optional base for pad or tank top mounting.
- Common system suction port and common system discharge port with "lost" flow detection sensor.
- System inlet strainer with liquid filled compound vacuum pressure gauge and differential pressure gauge for "clean" strainer alarm indication.
- Water absortion and polishing filter with color coded differential pressure display and change filter alarm indication
- Positive displacement gear pump with adjustable internal relief valve and UL listed totally enclosed fan cooled industrial motor. Shut-off valves and flanges are positioned so the pump may be removed for servicing without disturbing piping.
- Optional explosion proof motors or systems without pumps are also available.
- Check valve and liquid filled pressure gauges on each pump discharge.
- UL listed control panel, shipped loose for mounting in remote locations or system mounted, containing programmable logic controller, adjustable 7 day system timer, manual-off-auto illuminated pump mode selector switch, indicating lights, alarms and motor starter with overload protection.
- A wide range of purify sets and system control options are available to meet the specific requirements for each application.
